Reinforcement Scanning – Uses & Technical Details

What is Reinforcement Scanning?

Reinforcement scanning (also called rebar scanning) is a non-destructive testing (NDT) technique used to detect, locate, and map embedded steel reinforcement (rebar, mesh, ties) in concrete structures. It ensures safe drilling, coring, cutting, load assessments, and repairs without damaging structural integrity.

Common scanning tools include:

• Ground Penetrating Radar (GPR)


• Electromagnetic Cover Meters (e.g., Hilti Ferroscan, Profometer)


• X-ray Radiography (in specialized situations)

Primary Uses of Reinforcement Scanning

1. Pre-Drilling, Cutting, or Coring

Before core drilling or cutting into concrete (e.g., for HVAC, plumbing, or electrical installations), scanning helps avoid hitting rebar or conduits, which could weaken the structure or cause safety hazards.

2. Structural Load Assessments

Scanning provides data on rebar location, size, spacing, and concrete cover, which is essential for evaluating the load-carrying capacity of existing structures or for retrofitting designs.

3. As-Built Verification

Construction often deviates from drawings. Scanning helps produce accurate as-built documentation of reinforcement placement, ensuring quality control and long-term maintenance.

4. Concrete Condition Assessment

When investigating damage (cracks, delamination, corrosion), rebar scanning supports repair planning by pinpointing steel locations and evaluating corrosion-prone zones.

5. Rehabilitation and Strengthening Projects

For structural upgrades like carbon fiber wrapping, jacketing, or anchorage installation, knowing exact rebar layout helps avoid interference and design mistakes.

6. Quality Control and Compliance

Verifies that rebar placement matches design codes (ACI, Eurocode, IS) during construction inspections, especially for critical members like slabs, beams, and columns.
